BMT RADIAL DRILLING MILLING HEAD ER25 L=70 mm for BIGLIA
BMT RADIAL DRILLING MILLING HEAD ER25 L=70 mm for BIGLIA

BMT RADIAL DRILLING MILLING HEAD ER25 L=70 mm for BIGLIA

CAD $4,239.00

SKU: IMT201003 Brand:

IMT201003 / L30000395

Product Parameters

Tool Holder Turret Interface:

  • Tooling Interface: BMT-BOLT PATTERN 63×65 OD=54.7 BIGLIA
  • Power Coupling: DIN1809



IMTE No. Part No. ER Capacity Rotation Max.speed
(R.P.M.)		 Coolant
Supply
IMT201003 BIG-DF55-ER25-70 1~16 ER25 5000 external
For the detailed list of compatible machine models – please click the Compatible Machines tab
